01. What a Finite Automaton Is

The conversion from a nondeterministic finite automaton (NFA) to a deterministic finite automaton (DFA) is a basic technique used in regular expressions and in the lexical analysis of compilers, and it is also easy to implement.

In this chapter we pin down what a finite automaton is in the first place, and prepare one example that we will keep using all the way through the chapters that follow.

Finite Automata

A finite automaton is a machine made of nothing but states and transitions. It reads the input one character at a time, and moves from the state it is in now to the next state according to the character it read. If it is in a final state when it has finished reading the input, the input is “accepted”; if not, it is “not accepted”.

“Finite” means that the number of states is finite. All this machine can remember is “which state am I in now”, and neither how many characters it has read nor what came along the way is left over, beyond the part that has been folded into the distinction between states.

In exchange for being limited in what it can remember, the machine itself fits within a finite size. If there are 4 states and 2 kinds of symbols, then “from which state, on reading which character, do we go where” has only 8 possibilities. They can all be written out, and the machine can be run exactly as written.

Put the other way round, it cannot do anything like counting. Deciding whether ( and ) are lined up in the same number — a judgment like that is beyond the reach of a finite automaton. As long as the states are finite, a number that could grow arbitrarily large cannot be remembered.

Here is how to read the figures.

Notation	Meaning
Circle	A state
A circle with an arrow entering from the left	The start state
A double circle	A final state (accepting state)
An arrow, and the symbol beside it	The transition taken when that symbol is read
An orange arrow (ε)	It can transition without reading input (an ε transition)

Example

As the example we will use from here on, we take up the regular expression

a(a|b)*bb

It is the collection of strings that begin with a, continue with some number of as and bs, and end with bb. A finite automaton corresponding to this looks, for example, like the following.

Orange is an ε transition. Two ε transitions leave state 1, and whether it goes to 2 or to 4 is not determined by the input. A finite automaton in which the destination is not settled on a single one like this is called a nondeterministic finite automaton (NFA).

What the trouble is when the destination is not settled, and how to fix it, is handled in the chapters ahead.

The Road Ahead

Chapter	Contents
Chapter 02	Build an NFA from the regular expression a(a\|b)*bb
Chapter 03	Convert it into a form where the destination is settled on a single one (a DFA)
Chapter 04	Minimize the number of states of the DFA
Chapter 05	The implementation part begins here. Decide the range of regular expressions we handle
Chapter 06	Read a pattern and turn it into an NFA
Chapter 07	Turn it into a DFA, decide matches, and finish it as a command
