06. Reading a Pattern and Turning It into an NFA

We build everything up to taking a regular expression within the range decided in Chapter 05 and turning it into an NFA. There are 2 things to do: reading the pattern and extracting its structure, and applying the 4 rules of Chapter 02 (plus the 5th one added in Chapter 05).

1. Reading the Pattern

In the main part we had a human take in the structure of a(a|b)*bb by eye, but if we are making a tool, this too has to be done by a machine.

The operators of a regular expression have a binding strength, and in order from strongest they are * (repetition), concatenation, and | (union). For example, a|bb* is a union of a and bb*, not (a|b)b*.

So we write them down as 4 stages of rules, starting from the weakest operator.

alt  -> cat { '|' cat }      union         : concatenations lined up with |
cat  -> rep { rep }          concatenation : repetitions lined up
rep  -> atom { '*' | '?' }   repetition    : an element with * or ? attached
atom -> '(' alt ')' | CHAR   element       : a union enclosed in parentheses, or a single character

-> means “the left-hand side has this shape”, and { } represents a repetition of 0 or more times. The quoted '|', '*', '?' and '(' are the very characters that appear in the regular expression, and the unquoted | (in the rep and atom lines) is the “or” on the rule side.

Because a weaker rule is written so as to call a stronger rule, reading from the top in order gets the nesting out exactly according to the binding strength. The reason atom goes back to alt is for the parentheses, and this is where the nesting goes one level deeper.

The pattern string is looked at one character at a time from the beginning. What holds that reading position is _Parser, and it has only 2 operations.

class _Parser:
    def __init__(self, pattern):
        self.s = pattern
        self.i = 0

    def peek(self):
        return self.s[self.i] if self.i < len(self.s) else None

    def take(self):
        c = self.peek()
        if c is None:
            raise ValueError("unexpected end of pattern")
        self.i += 1
        return c

peek() only looks at the character at the current position; it does not move the position. take() returns the character at the current position and advances the position by one. That is, it reads one character forward. Once it comes to the end, peek() returns None, so the rule side knows from that that it is over.

What is being read here is the characters of the pattern, not the text being matched against. Reading the text one character at a time is the match decision that comes later (section 5 of Chapter 07).

What the Rules Produce — node

What the rules produce is a small tuple we call a node, whose head is the name of the kind and whose rest are the children. There are only 5 kinds.

In the place of a child, another node goes in. That is why a node is a tree.

The depth of the parentheses becomes, just as it is, the number of levels of the tree. The outermost star is the root, its child is alt, and its children in turn, the 2 syms, are the leaves.

Turning the Rules into Functions

The 4 rules of the grammar become, just as they are, 4 functions. Every one of them returns a node.

    def alt(self):
        node = self.cat()
        while self.peek() == "|":
            self.take()
            node = ("alt", node, self.cat())
        return node

    def cat(self):
        node = self.rep()
        while self.peek() not in (None, "|", ")"):
            node = ("cat", node, self.rep())
        return node

    def rep(self):
        node = self.atom()
        while self.peek() in ("*", "?"):
            node = ("star" if self.take() == "*" else "opt", node)
        return node

    def atom(self):
        c = self.take()
        if c == "(":
            node = self.alt()
            if self.peek() != ")":
                raise ValueError("')' expected")
            self.take()
            return node
        if c in "|*?)":
            raise ValueError(f"unexpected {c!r}")
        return ("sym", c)

alt, cat and rep all have the same shape. First they call the rule one level stronger once, and then, as long as the marker keeps coming, they take the node so far as the left child and wrap it up again.

Because atom calls alt back again, the functions recurse too. This way of reading is called recursive descent parsing.

The Result of Reading

Actually having it read a(a|b)*bb gives this.

>>> from automaton.regex import parse
>>> parse("a(a|b)*bb")
('cat', ('cat', ('cat', ('sym', 'a'), ('star', ('alt', ('sym', 'a'), ('sym', 'b')))), ('sym', 'b')), ('sym', 'b'))

The parentheses are deep and it is hard to read, but drawn as a tree it has a straightforward shape.

The reason 3 cats are lined up extending to the left is that the concatenation of the 4 items a, (a|b)*, b and b is brought together 2 at a time from the left. The (a|b)* portion is the branch star → alt → 2 syms.

We follow this tree in the next section and assemble the NFA.

2. Building the NFA

We apply the 4 rules seen in Chapter 02 (plus the 5th one added after this) to the node tree we read in.

The NFA we build into is nothing more than a container for accumulating states and transitions. state() adds one state, and add() adds one arrow.

class NFA:
    def __init__(self):
        self.n = 0        # number of states handed out so far
        self.edges = {}   # state -> [(symbol or EPS, state)], in construction order
        self.start = None
        self.accept = None
        self.label = {}   # state -> display name

    def state(self):
        """Add a fresh state and return it."""
        s = self.n
        self.n += 1
        self.edges[s] = []
        return s

    def add(self, s, sym, t):
        self.edges[s].append((sym, t))

The contents of the NFA are effectively just edges, and this is a dictionary from a “state” to a “list of the arrows leaving it”. The contents at the point where a(a|b)*bb has been finished correspond to this.

One element of the list, (symbol, destination), corresponds just as it is to one arrow in the figure. The reason (EPS, 2) and (EPS, 4) are lined up in the row for state 1 is that from 1 we can go by ε to 2 places, and the situation we called “the destination is not settled” in 02 shows up right here. The reason the row for the accepting state f is an empty list is that there are no arrows leaving it.

The keys of the dictionary are the numbers 0, 1, 2, …, and the names i, 1, 2, … written in the figure are held separately by label. The keys and the states correspond one to one. 0 is i and 6 is f; one key points at exactly one state.

With this way of holding things, looking at all the arrows leaving a given state takes only a single dictionary lookup. Writing edges[0] gives [('a', 1)], that is, the row for i in the figure comes back just as it is. Since both the ε closure and the subset construction are, in the end, this traversal, the later sections can be written short.

The remaining start and accept are there to remember one entrance and one exit. build puts the state created first into start, and into accept the return value of _build (= the state reached after finishing the construction of the whole pattern). The i and f in the figure are the labels attached to these 2.

What writes into this container is _build(nfa, node, s). The 3 arguments each have the following role.

Argument	Description
nfa	The NFA under construction. States and transitions get written into here
node	Which part of the pattern to build. Part of the tree read in the previous section
s	Where to build from. One already existing state

The return value is the state reached after finishing the construction.

For example, when node is ('sym', 'b') and s is state 4, _build makes a new state 5, draws one 4 -- b --> 5 arrow, and returns 5. s is the entrance, the return value is the exit, and what came into being in between is “the node’s share”. The next part is built with the returned 5 as its entrance.

Note that node is not the text being matched against, but the structure on the pattern side. As for direction, we read the node tree while writing into nfa. We are not assembling the tuples. The tuples already exist, and they serve as the blueprint.

Since the return value is “the state reached”, the concatenation of ② gets by with just “build b on from the end of a”. The line for cat being nested as _build(nfa, node[2], _build(nfa, node[1], s)) is exactly that, and there is neither a state nor an arrow newly added for the sake of the concatenation.

def _build(nfa, node, s):
    """Extend `nfa` from state `s` so that it accepts `node`; return the state reached."""
    kind = node[0]
    if kind == "sym":
        t = nfa.state()
        nfa.add(s, node[1], t)
        return t
    if kind == "cat":
        return _build(nfa, node[2], _build(nfa, node[1], s))
    if kind == "alt":
        left = _build(nfa, node[1], s)
        right = _build(nfa, node[2], s)
        nfa.merge(left, right)  # both branches end in the same state
        return left
    if kind == "opt":
        end = _build(nfa, node[1], s)
        nfa.add(s, EPS, end)     # skip the body entirely
        return end
    if kind == "star":
        body = nfa.state()
        nfa.add(s, EPS, body)
        end = _build(nfa, node[1], body)
        out = nfa.state()
        nfa.add(s, EPS, out)     # skip the body entirely
        nfa.add(end, EPS, body)  # go round again
        nfa.add(end, EPS, out)   # leave the loop
        return out
    raise ValueError(f"unknown node {kind!r}")

node[1] and node[2]

The node[0], node[1] and node[2] that appear in the code merely point at which position of the tuple from the previous section they are.

Element	For ('cat', a, b)	For ('star', a)
node[0]	'cat' — the name of the kind	'star'
node[1]	a — the one that comes first	a — the body that is repeated
node[2]	b — the one that comes after	(none)

This is why the line for concatenation is nested. Writing the same thing split over 2 lines gives this.

m = _build(nfa, node[1], s)        build the one that comes first from s. m is the state reached
return _build(nfa, node[2], m)     build the one that comes after from m, and return the state it reaches

The state returned by the inner call becomes the “where to build from” of the outer call. For ab, this means the state we arrive at after building a becomes, just as it is, the starting point for b.

And the state returned by the outer call — that is, the state we arrive at after finishing the construction of b — returns to the caller as the end of ab as a whole. Since every rule “returns the state reached after finishing the construction”, however many parts we join, it can be written the same way.

Lining up what the 5 rules do to edges gives the following.

There are 3 points worth noticing.

The concatenation of ② does not touch edges. It adds neither a new state nor a new arrow. It merely starts building b from the end state of a as it is, and that can be expressed entirely by “passing the return value of a as the 3rd argument of _build”.

The union of ③ does not add any arrow either. Building a and b separately ends up producing 2 end states, left and right, so we bring these together into one. What is done on top of edges is redirecting the arrows that pointed at right to left, and deleting the row for right — that is all. The b arrow in the figure being switched over from right to left is exactly that. The number of arrows does not change.

The one that adds ε is ④. 2 arrows in edges[s] (enter and skip), and 2 arrows in the row for the end of the body (go back and exit), 4 altogether. The 4 ε arrows we saw in 02 appear here as 4 elements of the form (EPS, destination).

In other words, what actually increases edges is one arrow per single symbol character (①) and 4 ε arrows per repetition (④). For a(a|b)*bb there are 5 symbols and 1 repetition, so 5 + 4 = 9 arrows. This agrees with the 9 we counted in Chapter 02.

The ⑤ we add after this also increases ε by only one arrow. ② and ③ add nothing at all, right to the end.

⑤ Optional x?

The ? we decided to add in Chapter 05 is the 3 lines of opt.

Build the body from s, and when we arrive at end, draw one ε from s to end. That becomes the road that “skips the body”. Not a single new state is made.

    if kind == "opt":
        end = _build(nfa, node[1], s)
        nfa.add(s, EPS, end)     # skip the body entirely
        return end

Building ab?, a b arrow and an ε arrow are lined up from 1 to f.

>>> from automaton.nfa import build, dump
>>> dump(build("ab?"))
 i -- a --> 1
 1 -- b --> f
 1 -- ε --> f

The merge used in ③ folds state drop into state keep. Since it is called from _build as merge(left, right), keep is left and drop is right. It concatenates the row for drop onto keep and then deletes it, and switches the transitions that pointed at drop over to keep.

    def merge(self, keep, drop):
        """Fold state `drop` into state `keep`."""
        if keep == drop:
            return
        self.edges[keep].extend(self.edges.pop(drop))
        for s, out in self.edges.items():
            self.edges[s] = [(sym, keep if t == drop else t) for sym, t in out]

Following what this concatenation and switching do to edges, in order from just before the call, gives this.

Note that drop is the state right after a branch has been finished, so there is not yet a single arrow leaving it. That is, the first concatenation actually moves nothing, and the only part that has an effect is the switching in the latter half (the concatenation is a generalization so that it does not break however it comes to be used).

Finally, the state numbers are renumbered. Not only do gaps appear in the numbering because of the merging, but the 1, 2, 3, ... in the figures of the main part are assigned in the order one passes through the machine, so they are reassigned in the order of a depth-first traversal from the start state (_renumber in automaton/nfa.py).

>>> from automaton.nfa import build, dump
>>> dump(build("a(a|b)*bb"))
 i -- a --> 1
 1 -- ε --> 2
 1 -- ε --> 4
 2 -- a --> 3
 2 -- b --> 3
 3 -- ε --> 2
 3 -- ε --> 4
 4 -- b --> 5
 5 -- b --> f

Both the edges and the names of the states agree with the 9 we assembled by hand in Chapter 02.

---

Up to here, we have become able to build an NFA from any pattern whatsoever. In Chapter 07, we turn this into a DFA and carry it through to the match decision.
