Writing MCP with the SDK

Alice and Bob building a block castle together

In the previous chapter we followed the four exchanges as raw JSON-RPC. Let’s write the same thing with the official SDK.

Writing the server

It is src/server/main.py. Per tool, this is all that is needed (three are actually registered, but here only search is extracted).

from mcp.server.mcpserver import MCPServer

mcp = MCPServer("rag-search-server")

@mcp.tool()
def search(query: str, top_k: int = 5) -> str:
    """
    Search the documents of a cafe called The Wandering Kettle.

    Use this to answer questions about the menu, prices, opening hours,
    location, wifi and power sockets, allergies and dietary options, the
    staff handbook, and the history of the shop.
    """
    ...

if __name__ == "__main__":
    mcp.run()

A function with @mcp.tool() attached becomes a tool as it is.

What “becomes a tool” means here is that the response to tools/list is built automatically from the function. In the previous chapter, this response came back.

{
  "name": "search",
  "description": "Search the documents of a cafe called The Wandering Kettle. ...",
  "inputSchema": {
    "type": "object",
    "properties": {
      "query": {"type": "string",  "title": "Query"},
      "top_k": {"type": "integer", "title": "Top K", "default": 5}
    },
    "required": ["query"]
  }
}

This JSON is written nowhere. It is assembled from the search above.

Contents of the response	Where in the function it came from
`"name": "search"`	The function name `def search(...)`
`"description"`	The docstring
`query` / `top_k` in `properties`	The argument names
`"type": "string"` / `"integer"`	The type hints `query: str` / `top_k: int`
`"title": "Query"`	Attached automatically from the argument name (for display)
`"default": 5`	The default value `top_k: int = 5`
`"required": ["query"]`	The arguments that have no default value

top_k has a default value, so it does not go into required. Write no type hints, and the type cannot be determined, and the tool breaks.

[!TIP] What the decorator @mcp.tool() is — a Python note

A line starting with @ is called a decorator, a mark attached to the function right after it. search itself remains an ordinary Python function, and nothing about how it is written changes. Add one line above it, and it comes to mean “expose this function as an MCP tool”. It is the same idea as writing @app.route("/search") in a web framework to turn a function into a URL.

Because how the function is written becomes the specification as it is, there are rules when writing a tool.

Attach type hints to the arguments. Leave them out, and the inputSchema cannot be built

Write a docstring. It becomes the explanatory text the LLM reads (see the next NOTE)

The function name becomes the tool name as it is. With f or do_it, the LLM cannot choose it

Whatever you return reaches the LLM as it is. It goes into content in the tools/call response. In this project we return a single piece of already formatted text

Do not print to stdout. That is the path of JSON-RPC. Logs go to stderr

As long as you keep to the rules, the work of adding more exposed tools becomes just “write a function and attach @mcp.tool()”.

mcp.run() listens over stdio. The processing we saw in the previous chapter, “reading and writing newline-delimited JSON”, is inside it.

[!NOTE] The docstring is an instruction to the LLM

It is not a comment for humans. This text is handed to the LLM as description and becomes the material for deciding in what situations to call this tool. Write not only “what it does” but “what kinds of question it can be used for”.

Writing the client

It is steps/03_mcp_sdk.py.

One thing before reading it. With stdio, the client starts the server as a child process (the previous chapter). There is no need to bring the server up first in another terminal. Run the client, and the server starts inside it.

The code that does this is as follows.

from mcp import ClientSession, StdioServerParameters
from mcp.client.stdio import stdio_client

# ① Write down how to start the server. Nothing is started here yet
SERVER = StdioServerParameters(
    command="uv",
    args=["run", "python", "-m", "server.main"],
)

# ② Start it and have the conversation
async with stdio_client(SERVER) as (read, write):
    async with ClientSession(read, write) as session:
        info = await session.initialize()
        tools = (await session.list_tools()).tools
        result = await session.call_tool("search", {"query": "can I bring a dog", "top_k": 1})

①’s StdioServerParameters merely writes down the startup command. Join command and args together and it becomes uv run python -m server.main. It is the same command you would type to start the server by hand.

②’s stdio_client actually starts that command as a child process. It corresponds to the part where we wrote subprocess.Popen in the previous chapter. The started child process’s standard input and output are read / write, and ClientSession pours JSON-RPC into them.

The remaining 3 lines are the conversation.

info = await session.initialize()
tools = (await session.list_tools()).tools
result = await session.call_tool("search", {"query": "can I bring a dog", "top_k": 1})

initialize() opens the connection. Without calling this, you cannot call anything else (previous chapter)
What list_tools() returns is not the list itself but an object wrapping it. The array of tools is taken out with .tools
To call_tool() you pass the tool name and a dictionary of arguments. The arguments follow the inputSchema. They are the same as what we put in params’ name and arguments in the previous chapter

All of them have await attached. That is because they wait until the response comes back.

[!TIP] async and await — a Python note

The MCP SDK’s client API is entirely asynchronous. That is because the processing writes one line into a pipe and waits until one line of reply arrives.

There are only three things to remember in order to use it.

Call with await attached. Forget it, and what comes back is not the result but “a reservation to run”, and no communication happens

await can only be written inside an async def. That is why this whole processing is put inside async def main()

An async def function does not run just by being called. Start it with asyncio.run(main())
async def main():
    ...
    info = await session.initialize()

asyncio.run(main())
async with is also the same as with: it cleans up when leaving the block. The only difference is that there is waiting time in that cleanup too.

“You can get other work done while waiting” is the advantage of being asynchronous, but in this material we only wait for things one at a time in order, so we are not using that benefit. You can think of it as matching the way the SDK is written.

Leave the async with, and the connection closes and the server exits too. The previous chapter’s proc.stdin.close() does not need to be written.

Lining up in order what happens to ① and ② at runtime, it looks like this. The numbers in the figure correspond to the numbers in the code comments.

The server is started by the client as a child process, and exits on its own when the connection closes

At the point of ①, the server’s process does not exist yet. It starts for the first time at ②, and disappears when the async with is left at ③.

In the actual code, two arguments are added.

SERVER = StdioServerParameters(..., env=dict(os.environ))
async with stdio_client(SERVER, errlog=subprocess.DEVNULL) as (read, write):

Argument	Why it is needed
`env`	Passes environment variables to the child process. Without `RAG_CHROMA_PATH` it cannot find the database
`errlog`	Where the server’s stderr goes. By default it appears on screen, so we throw it away to make things readable

Let’s run it.

docker compose exec app uv run python steps/03_mcp_sdk.py

[1] session.initialize()
    server   : rag-search-server
    version  : 2025-11-25

[2] session.list_tools()
    name     : search
    arguments: ['query', 'top_k']
    required : ['query']
    name     : list_documents
    arguments: []
    required : []
    name     : get_document
    arguments: ['name']
    required : ['name']

[3] session.call_tool()
    is_error : False
    content  : 1 block(s), type text
    text     : 1689 characters
    first    : [1] source: faq.txt (distance: 0.21)

Four exchanges become three calls

The previous chapter’s message	The call in the SDK
`initialize`	`session.initialize()`
`notifications/initialized`	Included in the above
`tools/list`	`session.list_tools()`
`tools/call`	`session.call_tool(name, arguments)`

② has disappeared. initialize(), after sending the request and receiving the response, goes on to send the notification as well. There is no longer any worry about forgetting the message with no reply.

What the SDK does on your behalf

What we wrote ourselves in the previous chapter	In the SDK
Starting the server with `subprocess.Popen`	`stdio_client` starts it
`json.dumps` / `json.loads`	Not needed
Numbering `id` as 1, 2, 3	Numbered automatically and matched up with the responses
Sending the notification and taking care not to receive	Included in `initialize()`
Finishing with `proc.stdin.close()`	It closes when you leave the `async with`

In terms of line count, it goes from 229 lines to 87 lines.

The return values are typed objects, not dictionaries

In raw JSON, everything was a dictionary.

result["result"]["content"][0]["text"]     # previous chapter

The SDK returns typed objects.

result.content[0].text                     # this chapter

The attributes used in this project are as follows. On the left is the JSON key we saw in the previous chapter, and on the right is the attribute that reads it.

session.initialize() → InitializeResult

The previous chapter’s JSON	Attribute	Contents
`serverInfo.name`	`.server_info.name`	The server name
`protocolVersion`	`.protocol_version`	The agreed version
`capabilities`	`.capabilities`	What the server can do

session.list_tools() → ListToolsResult

The previous chapter’s JSON	Attribute	Contents
`result.tools`	`.tools`	A list of `Tool`
`name`	`.tools[0].name`	The tool name
`description`	`.tools[0].description`	The description
`inputSchema`	`.tools[0].input_schema`	The argument definitions

session.call_tool(name, arguments) → CallToolResult

The previous chapter’s JSON	Attribute	Contents
`content`	`.content`	A list of `TextContent`
`type`	`.content[0].type`	The kind (`"text"`)
`text`	`.content[0].text`	The body
`isError`	`.is_error`	Whether the tool failed

There is the advantage that a mistyped key is caught before running.

[!NOTE] Python’s attribute names and the keys that actually flow as JSON are different things

Tool’s attribute is input_schema, but the JSON key is inputSchema. The attribute names merely became more Pythonic in SDK v2; what the specification decides is the JSON side.

What we have learned so far

A function with @mcp.tool() attached becomes a tool as it is
description is built from the docstring, and inputSchema from the type hints
The SDK takes over starting the process, JSON conversion, id management, the notification, and the shutdown handling
Four messages become three calls. The notification is included in initialize()
The return values are typed objects, not dictionaries

In the next Step 4, we put the LLM on top. We hand the tool definitions to the LLM and let the LLM decide which tool to call. That is where RAG is completed.
