Speaking MCP in raw JSON-RPC

Alice and Bob playing with a frisbee

This is the main subject from here on. The search() we prepared in the previous chapters — we call it from another process. The agreement for doing that is MCP.

What is exchanged is JSON

In this chapter we read and write JSON. Only two symbols are needed.

Symbol	Meaning
`{ }`	A pair of a name and a value. The name is always a string, written as `"name": value`
`[ ]`	A sequence. Values are put in, separated by commas

Besides strings, numbers, and booleans, values can contain { } and [ ] as they are. This nesting is all there is to JSON.

{
  "name": "search",
  "top_k": 3,
  "results": ["hours_access.txt", "staff_handbook.txt"],
  "options": {"prefix": "query: "}
}

The value of results is a [ ] sequence, and the value of options is a { }. In a value’s position, you can again place either { } or [ ].

Newlines and indentation are there for readability and have nothing to do with the meaning. When actually sending, it is written on one line.

{"name": "search", "top_k": 3, "results": ["hours_access.txt", "staff_handbook.txt"], "options": {"prefix": "query: "}}

These two are the same thing.

The container is JSON-RPC 2.0

It is not the case that you can arrange JSON however you like. It rides on an existing agreement called JSON-RPC 2.0. It is for “calling something that exists in another process by name”, and what it decides is only the names of the fields.

The calling side.

Name	Contents
`jsonrpc`	Always `"2.0"`
`id`	The request’s number. Used to match it up with the reply
`method`	The name of the thing you want to call
`params`	The arguments. Omitted if there are none

The replying side.

Name	Contents
`jsonrpc`	Always `"2.0"`
`id`	Indicates which request this is a reply to
`result`	The result

{"jsonrpc": "2.0", "id": 2, "method": "tools/list"}
{"jsonrpc":"2.0","id":2,"result":{"tools":[ ... ]}}

The upper one is the request, the lower one the reply. The id is the same, so the correspondence is clear.

What JSON-RPC decides is only this container. What decides which names can be used in method — initialize, tools/list, tools/call — is MCP.

What is MCP

It stands for Model Context Protocol. As the name says, it is an agreement for handing external context to a model (an LLM), and it is used to connect applications with external tools.

The side that provides tools is called the server, and the side that uses them is called the client.

The client and the server are separate processes, exchanging one-line JSON through standard input and output

In this material the server is src/server/main.py, which has the previous chapter’s search(). The client is steps/02_mcp_raw.py.

Why separate them? In the same process you could just call search() directly. By separating them, you can call a tool written in another language, or a tool on another machine, with the same procedure. What MCP decides is that procedure.

The transport is standard input and output

MCP has several transport methods, but this material uses stdio (standard input and output).

The client starts the server as a child process
Writing to the server’s standard input = sending
Reading from the server’s standard output = receiving

There is no length header, no framing, no custom handshake. A newline is the end of one message, and the contents are just JSON-RPC 2.0.

proc.stdin.write(line + "\n")   # the newline is the end of the message
proc.stdin.flush()              # without this, the server keeps waiting
line = proc.stdout.readline()   # receiving is also just reading one line
proc.stdin.close()              # closing = the signal to finish

Sending and receiving are effectively only 3 lines. There is no termination message either; closing standard input is itself the signal that it is over. The server receives EOF and exits on its own.

[!NOTE] The server’s logs must not go to stdout

Standard output is the transport. Mixing in a single print() breaks the JSON. That is why the server-side logs must always go to stderr.

Calling search once, with four messages

Let’s run steps/02_mcp_raw.py. It is a client that uses no SDK and builds by hand the exchange of writing one line of JSON and reading one line.

docker compose exec app uv run python steps/02_mcp_raw.py

What it does is just call search() once, but four messages flow before getting there.

The four messages the client and server exchange. The three that carry an id get responses; the notification does not

The three that carry an id get responses, and ②, which has no id, does not. Let’s look at them in order. All of the following are lines that actually flowed.

1. initialize — opening the connection

Put initialize in method and send it. It is fixed that this is the first thing you send after connecting. You tell it the version you can speak (protocolVersion) and your own name (clientInfo).

{
  "jsonrpc": "2.0",
  "id": 1,
  "method": "initialize",
  "params": {
    "protocolVersion": "2025-06-18",
    "capabilities": {},
    "clientInfo": {"name": "raw-client", "version": "0.1.0"}
  }
}

It comes back.

{
  "jsonrpc": "2.0",
  "id": 1,
  "result": {
    "capabilities": {"tools": { ... }, ... },
    "protocolVersion": "2025-06-18",
    "serverInfo": {"name": "rag-search-server", "version": ""}
  }
}

The id corresponds. For the id: 1 we sent, it comes back with id: 1. Even if you throw multiple requests at once, you can tie the replies together by id.

capabilities is the server’s declaration of what it can do, and it says it has tools. Because that is there, we can ask tools/list next. (prompts and resources are listed too, but they are not used in this material, so they are omitted)

protocolVersion is the version the replying side agreed on. If the server does not know the version you sent, it is not an error; the version the server can speak comes back. The client matches it if it can speak that one, and gives up on the connection if it cannot.

[!NOTE] Send it first, or you are refused

Skip initialize and send tools/list, and you get error instead of result.
{"jsonrpc":"2.0","id":1,"error":{"code":-32602,"message":"Invalid request parameters","data":""}}
That error goes in instead of result when something fails is also a JSON-RPC rule.

2. notifications/initialized — the message with no reply

Once you have received the reply to initialize, you tell the server that you are ready. With this, the connection procedure is over, and from then on you can call tools.

{
  "jsonrpc": "2.0",
  "method": "notifications/initialized"
}

You are only telling it something; there is nothing you want to ask the server. So there is no params, and no id either. This is a notification. It is not a request, so no reply comes back.

Try to receive here, and it blocks until the next response arrives. The presence or absence of an id decides “whether to wait for a reply” — that is how JSON-RPC is built.

3. tools/list — asking about the tools

{
  "jsonrpc": "2.0",
  "id": 2,
  "method": "tools/list"
}

What comes back is the tool definitions. In reality it is 1996 characters on one line.

{
  "jsonrpc": "2.0",
  "id": 2,
  "result": {
    "tools": [
      {
        "description": "\nSearch the documents of a cafe called The Wandering Kettle.\n\nUse this to answer questions about ...",
        "inputSchema": {
          "properties": {
            "query": {"title": "Query", "type": "string"},
            "top_k": {"default": 5, "title": "Top K", "type": "integer"}
          },
          "required": ["query"],
          "type": "object",
          "title": "searchArguments"
        },
        "name": "search",
        "outputSchema": { ... }
      },
      {
        "description": "\nList the names of the document files that can be searched.\n\n...",
        "inputSchema": {
          "properties": {},
          "type": "object",
          "title": "list_documentsArguments"
        },
        "name": "list_documents",
        "outputSchema": { ... }
      },
      {
        "description": "\nReturn one document file in full, by its exact file name.\n\n...",
        "inputSchema": {
          "properties": {
            "name": {"title": "Name", "type": "string"}
          },
          "required": ["name"],
          "type": "object",
          "title": "get_documentArguments"
        },
        "name": "get_document",
        "outputSchema": { ... }
      }
    ]
  }
}

(The body of description and the contents of outputSchema are long, so they are omitted)

tools is an array. This server has three, so three items are listed. Each item contains name / description / inputSchema.

Tool	What it does	Arguments
`search`	Finds documents close in meaning	`query`, `top_k` (default 5)
`list_documents`	Lists the file names	None
`get_document`	Returns one file in full	`name`

inputSchema differs per tool. list_documents has no arguments, so properties is empty and there is no required either. For get_document, name is required.

The client looks at this list and learns what tools there are. It does not need to know in advance; it just asks with tools/list.

inputSchema is JSON Schema. It states the argument names, types, defaults, and whether they are required. The arguments you send with tools/call follow this.

description is free text, and the one who reads it is the LLM. It is there to convey “in what situations to use this tool”.

4. tools/call — having it executed

{
  "jsonrpc": "2.0",
  "id": 3,
  "method": "tools/call",
  "params": {
    "name": "search",
    "arguments": {"query": "can I bring a dog", "top_k": 1}
  }
}

In params, you put the tool name and the arguments. The arguments follow the inputSchema that came back from tools/list.

It comes back. In reality it is 3609 characters on one line.

{
  "jsonrpc": "2.0",
  "id": 3,
  "result": {
    "content": [
      {
        "text": "[1] source: faq.txt (distance: 0.21)\npassage: \nThe Wandering Kettle - ...",
        "type": "text"
      }
    ],
    "isError": false,
    "structuredContent": { ... }
  }
}

(The body of text and the contents of structuredContent are long, so they are omitted)

The result goes into an array called content. The elements are distinguished by type, which here is text. The contents of text are 1689 characters, exactly the string the previous chapter’s search() returned.

isError conveys success or failure. Even if an exception occurs inside the tool, it does not become a JSON-RPC error; this value comes back as true.

It is here, for the first time, that ChromaDB ran on the other side of the process boundary. The client has not imported ChromaDB, nor does it have the embedding model.

What we have learned so far

MCP’s stdio transport is just writing and reading newline-delimited JSON. Close it and it is over
With an id it is a request, without one a notification. That decides whether to wait for a reply
The inputSchema that tools/list returns is JSON Schema. The shape of the arguments is decided here
The result of tools/call comes back as a content array
The agreed version is in the server’s reply
No LLM has appeared even once up to here. The LLM has nothing to do with MCP’s communication

The SDK is merely hiding these four exchanges. In the next Step 3, we write the same thing with the official SDK and see what can be left out.
