Running ChromaDB

Alice and Bob playing with a paper plane

What is ChromaDB

It is a vector database. Hand it a string, and it converts it into “a sequence of numbers that expresses meaning”, that is, a vector, and stores it; hand it a question, and it returns things in order of closeness.

With an ordinary database you could look things up with LIKE '%warm%'. But with that, you cannot retrieve Espresso drinks arrive steaming from the question “I want a warm drink”. Because the characters do not match.

Sentences with similar meanings become vectors pointing in similar directions, while unrelated sentences do not align

Turn sentences into vectors, and closeness of meaning becomes closeness of direction. ChromaDB returns this difference in direction as a distance, and lines them up from smallest to largest.

Reading the code

Of steps/01_chromadb.py, only four lines are involved in the flow of searching. (Besides these, it uses get() to peek at the stored vectors and count() to count the items)

client = chromadb.Client()                    # open the database
collection = client.create_collection(...)    # create a collection
collection.add(...)                           # register the documents
collection.query(...)                         # search with a question

Let’s look at them in order.

Preparing the embedding function

Build the part that turns strings into vectors.

from chromadb.utils.embedding_functions import SentenceTransformerEmbeddingFunction

embedding_function = SentenceTransformerEmbeddingFunction(
    model_name="intfloat/multilingual-e5-small"
)

It takes a list of strings and returns a list of 384-dimensional vectors. That is all this part does.

Creating a collection

client = chromadb.Client()          # In memory. It disappears when the process ends
collection = client.create_collection(
    name="cafe",
    embedding_function=embedding_function,
)

A collection is where documents are kept; it corresponds to a table in an RDB. If you want to keep it on disk, use chromadb.PersistentClient(path=...).

The embedding function is tied in here. From then on, both add() and query() call it internally, so there is no point at which the calling side handles vectors directly.

Registering documents — `add()`

Let’s first build what we pass in. Read the .txt files in data/documents and make a list.

files = []
for txt_file in sorted(DOCUMENTS_PATH.glob("*.txt")):
    content = txt_file.read_text(encoding="utf-8")
    files.append({"filename": txt_file.name, "content": content})

txt_file.name is the file name, and content is its contents. So files becomes a list with one dictionary per file, which for 7 files means 7 items. The first item looks like this.

{"filename": "allergens.txt", "content": "The Wandering Kettle - Ingredients..."}

We rearrange this into two lists and pass them in.

collection.add(
    ids=[f["filename"] for f in files],
    documents=[DOCUMENT_PREFIX + f["content"] for f in files],
)

That is, ids is a list of file names and documents is a list of file contents.

ids       = ["allergens.txt", "faq.txt", "hours_access.txt", ...]
documents = ["passage: The Wandering Kettle - Ingredients...",
             "passage: The Wandering Kettle - Questions...", ...]

Both have 7 items, in the same order. ids[0] and documents[0] point to the same file.

ids only has to be unique. Here we use the file names as they are. The strings passed to documents become vectors as they are.

[!NOTE] What DOCUMENT_PREFIX really is
DOCUMENT_PREFIX = "passage: "
QUERY_PREFIX = "query: "
E5-family models are trained with separate markers attached to stored documents and to search queries. They still work if you forget to attach them, but accuracy drops. It is a convention fixed per model.

Searching with a question — `query()`

results = collection.query(
    query_texts=["query: What time do you close on Friday?"],
    n_results=3,
)

The question becomes a vector through the same embedding function. Since n_results=3, 3 items come back.

>>> results["ids"]
[['hours_access.txt', 'staff_handbook.txt', 'menu_food.txt']]

>>> results["distances"]
[[0.1989266276359558, 0.20826709270477295, 0.21306967735290527]]

What is lined up in ids are the file names we passed in at add() time. distances are the respective distances, and the smaller, the closer to the question. The order is from smallest distance, so the first one, hours_access.txt, is in 1st place, and the third item, menu_food.txt, is in 3rd place.

And both lists are doubly nested. The 3 items on the inside are the search results, and the outside is per question. query_texts is a list, so throw in 2 questions and the outside has 2 items.

>>> r = collection.query(query_texts=["query: What time do you close on Friday?",
...                                    "query: Do you have oat milk?"], n_results=2)
>>> r["ids"]
[['hours_access.txt', 'staff_handbook.txt'], ['allergens.txt', 'menu_drinks.txt']]

The outside is a list even with one question, and the inside is a list even with n_results=1. The shape does not change even with a single element, so you cannot leave out the subscripts.

In other words, you select the question with the outer subscript and the rank with the inner subscript. With n_results=3 returning 3 items, getting the 1st place means following two levels.

results["ids"][0]             # the results for the first question. 3 items in it
                              # -> ['hours_access.txt', 'staff_handbook.txt', 'menu_food.txt']
results["ids"][0][0]          # the 1st place among them -> 'hours_access.txt'
results["documents"][0][0]    # the body of the 1st place
results["distances"][0][0]    # the distance of the 1st place -> 0.1989266276359558

Running it and checking

Running is done inside a Docker container. Start the container at the top of the project.

docker compose up -d

Once it is up, run the script inside the container.

docker compose exec app uv run python steps/01_chromadb.py

If you are going to try it many times, it is faster to go into the container. Inside is an ordinary Ubuntu, and the working directory is /workspace.

docker compose exec app bash
uv run python steps/01_chromadb.py

The first run takes a while, because the embedding model (about 470MB) gets downloaded. From the second run on, it is read from the cache.

There is no procedure for creating the database in advance. ChromaDB is created in memory, and it disappears when the run finishes. You can redo it as many times as you like.

Trying it interactively

To try it while changing the question, start Python in interactive mode.

docker compose exec app bash
uv run python

The following 7 lines put you in the same state as the script.

import chromadb
from pathlib import Path
from chromadb.utils.embedding_functions import SentenceTransformerEmbeddingFunction

ef = SentenceTransformerEmbeddingFunction(model_name="intfloat/multilingual-e5-small")
collection = chromadb.Client().create_collection("demo", embedding_function=ef)
for p in sorted(Path("data/documents").glob("*.txt")):
    collection.add(ids=[p.name], documents=["passage: " + p.read_text()])

After that you can call query() directly. The >>> output we saw above can be reproduced here.

>>> r = collection.query(query_texts=["query: Do you have oat milk?"], n_results=2)
>>> r["ids"]
[['allergens.txt', 'menu_drinks.txt']]

Rewrite what comes after query:, and you can try any question.

When you are done, stop the container.

docker compose down

The embedding model’s cache stays in a volume, so it is not re-downloaded next time. If you want to delete it, use docker compose down -v.

[!NOTE] Installing Docker is in What you need and installing Docker, and building and day-to-day operations are in Setting up a working environment.

The material is the 7 files of the fictional cafe The Wandering Kettle, placed in data/documents/. The following is an excerpt of the output.

It can be retrieved even when no word matches

  Question: I want something warm to drink because it is freezing outside
    distance 0.165  menu_drinks.txt
    "warm" appears in that file: False
    "freezing" appears in that file: False
    "outside" appears in that file: False

Keyword search would never return this. What is written there is a different expression.

Espresso drinks arrive steaming in a heavy ceramic cup that keeps
its temperature for a good twenty minutes.

steaming sits in a position close to “warm” within the space.

How to read the distance

The distance is a cosine distance, and the better the directions align, the closer it gets to 0. The absolute value carries no meaning; look only at the ranking within the same search.

What we have learned so far

What you hand to ChromaDB is strings. Vectorization happens on the library’s side
Regardless of length, one document becomes one 384-dimensional vector
Vector search is not looking at word matches. That is why paraphrases retrieve things too
The distance is a cosine distance. Read it as a ranking, not as an absolute value

In the next chapter, we build this database on disk ahead of time and prepare a search() that can be called later.
